Make a Statement with Custom Wall Printing Installations! Turn ordinary walls into extraordinary focal points with our custom wall printing installations. Whether it's a corporate office, a retail space, or a hospitality venue, our wall printing technology can create immersive and captivating designs that leave a lasting impression. Elevate your environment, spark conversations, and showcase your unique style with our bespoke wall printing installations. |
![]() |
![]() |
Product Advantages: |
1. 2pc 4720 Print Head, CMYK water-based ink
2. Waterproof,anti-corrosion,anti-scratch and anti-wear.
3. No fading outdoors for five years, no fading indoors for ten years.
4. Computer automatic color grading.
5. Environmentally friendly and durable.
6. Suitable forindoor and outdoor all kinds of walls.
Products Parameters: |
Equipment model | BK-UP900P | |
Printing software | Genuine professional | |
Use ink | MYCK water-based ink | |
Nozzle specification (Epson) | Epson 4720 high precision nozzle 2pcs | |
level | Imported precision level | |
electric machinery | 3 imported intelligent motors + reducers | |
Wall detection | 2 ultrasonic distance detectors | |
Laser positioning | Precise infrared laser positioning system | |
Ground rails | High strength precision rail, 3 sections, 4.5m, | |
Shaft guide | Imported linear drive module | |
Print operation platform | Computer | |
Control mode | Wired / wireless printing | |
Transportation carrying | (folding) | |
Power consumption | No load 20W, maximum 250W | |
Surface tracking | Hyperboloid banner sensor,up-down bidirectional induction | |
Ink supply system | Positive pressure system ink supply | |
Print size | 2.5 meters high × Any width,more than 2.5m, can be seamlessly spliced | |
Construction noise | Standby < 20dBA, drawing < 70dba | |
Support picture | Photos taken by mobile phone / camera and online pictures | |
Power requirements | Household power 220VAC or 380VAC | |
Applicable media | White wall, putty wall, ceramic tile, glass, acrylic, metal plate, brick wall, etc | |
National film format | Including psd.cdr, JPG, JPEG, PNG, BMP, tiff, EPS, AI, PDF and other formats | |
Color painting technology | Micro piezoelectric jet technology, variable ink drop, high fault tolerance feathering technology, automatic memory recovery technology after construction interruption | |
Print Resolution | 360x720dpi/720x1080dpi/720x1440dpi/1080x1440dpi/1440x2880dpi | |
Operating environment | -20°C-50°C(-4F-122F),10%-70% Relative humidity, non condensing state | |
Storage environment | -21C-5o°C(-22F-140°F),10%-70% Relative humidity, non condensing state | |
Nozzle advantages | You can work all day | |
Overall dimension | Machine ruler (mm);Length 700x width 300X height 2600 | Package size (mm): 1610L x 830W x 610 H |
Machine weight | Machine 55kg | Packed in wooden cases, weighing 155kg |
machine language | Chinese / English/ Multi languages |
Applicaitons: |
|
Machine Introduction: |
![]() |
1. Equipped with Professional Industrial Print Heads
|
2. Control Computer
|
![]() |
![]() |
3. CMYK 4 Color water-based Ink and Ink Supply System
|
4. Laser Positioning System
|
![]() |
Print Technology: |
Our machine can print in blocks and seamlessly connect to achieve perfect results!
![]() |
![]() |
A. When the height of the image is within 3 meters,the print length can be extended indefinitely(infinite extension through the ground rail cycle splicing), the printer does not require partition printing, create the perfect picture at once. | B. When you need to print images over 3 meters,using scaffolding to raise the machine, the print length can be extended indefinitely(infinite extension through the ground rail cycle splicing) , then partition print. |
![]() |
![]() |
C. When the height of the frame exceeds 3 meters , when the length does not exceed the length of the machine guide rail (fixed image size), the picture can be divided into multiple areas(1,2,3....6 etc.) ,then partition print. | D. When the height of the frame exceed 6 meters , when the length exceeds the length of machine rail(guide rail can be cyclically spliced to achieve image length), When you need to print different partitions, the picture can be divided into multiple areas(1,2,3...6 etc.), then partition print. |
More Chioces: |
![]() |
![]() |
Packing and Delivery: |
About US: |
Wuhan Baike intelligent Technology Co., Ltd Founded in 2008. We are a professional laser manufacturing company under Wuhan Baike Times Laser Technology Co., Ltd. Our company has developed more 1000+ kinds of laser products, has been widely used in all walks of life, product quality and service has been praised by customers.Our product footprints are spread across all walks of life around the world, and our product quality and services have been 100% praised. Baike is committed to providing innovative industrial laser solutions to customers around the world! Welcome to visit our factory at any time in Wuhan City, China! |
FAQs: |
Q1: Are you a factory or a trading company? Q2: How long is the warranty period after purchasing the machine? Q3: How soon can the delivery be made after payment? Q4: How long can the printed patterns remain on the wall? Q5: How much ink is consumed for printing patterns? Q6: What should I do if I no longer want the printed pattern on the wall? Q7: What language settings are available on the machine? Q8: How do you handle uneven ground during printing? Q9. How is the quality of the machine? Are there any components that are prone to damage? Q10. Can one print head be used for printing four colors, while another print head is dedicated to printing white? |
